Web Client

Web client connects to and displays the 3D model from Sym3 Operator Server.

Settings

The configuration for the web client is located in the ‘Web Client’ tab on the Settings page. See the Settings documentation.

Overview

The web client features a toolbar and side panels.

Equipment Search

The search box allows users to quickly complete searches by equipment name. The first 10 matched equipment items will be listed in the drop-down list for users to select.

The 3D camera will focus on the selected equipment.

Buttons

The table below contains descriptions for each button.

Button	Description
Product Tracking	Open and close the product tracking panel
Cameras	Open and close the camera list panel
Alarms	Open and close the alarm panel. The badge displays the number of active alarms.
Fullscreen	Toggle fullsceen mode
2D/3D Mode	Toggle between 2D and 3D mode
Map Mode	Toggle between map mode and 3D rotation mode
Dark/Light Background	Toggle between dark and light background

Product Tracking

The product tracking panel generates the filter list based on the properties of the products in the 3D model.

Check one or more properties to display user properties on top of the products. The filter box allows users to filter the displayed properties to show only those for specific products.

Click the ‘CLEAR’ button to reset all filter settings.

Cameras

The 3D model may include multiple cameras. The camera panel lists all available cameras. Click on a camera name to set the camera.

The selected camera will be highlighted in the list.

Alarm Display

The panel displays the active alarm records. Click a record to focus the camera on the corresponding equipment.
